CARACTERÍSTICAS DE HARDWARE
Interface 1× 10/100/1000 Mbps RJ45 WAN Port
3× 10/100/1000 Mbps RJ45 LAN Ports
Botão Reset Button, WPS/Wi-Fi Button
Fonte de Alimentação Externa 12V/1A
Dimensões (L X C X A) 7.2 × 3.7 × 1.3 in (182.7 × 94 × 33.3 mm)
Tipo de Antena Four External Antennas
CARACTERÍSTICAS WIRELESS
Padrões Wireless IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11n/g/b 2.4 GHz
Frequência 2.4 GHz and 5 GHz
Taxa de Sinal AX1800
5 GHz: Up to 1201 Mbps (HE80)
2.4 GHz: Up to 574 Mbps (HE40)*
Funções Wireless Enable/Disable Wireless Radio, WMM, Wireless Statistics, Band Steering
Segurança Wireless WPA/WPA2/WPA3 Encryptions
Potência de Transmissão CE: <20dBm (2.4 GHz), <23dBm (5.17 GHz–5.71 GHz)
Agendamento Wireless Support 2.4 GHz and 5 GHz Wireless Schedule
Mesh Technology EasyMesh Compatible, and support 802.11k/v/r
CARACTERÍSTICAS DE SOFTWARE
Características Avançadas Muti-SSID, Guest Network, QoS (Quality of Service), TX Beamforming, MU-MIMO, OFDMA, Airtime Fairness
Modos de Operação Router, Access Point
Tipo de WAN Dynamic IP/Static IP/PPPoE/PPTP/L2TP (Multi-EWAN)
Gerenciamento Local management: WebGUI, Aginet app (for end users)
Remote management: TR-069, TR-098, TR-181, TR-369, TR-111,TR-143 for service providers
Aginet App for end users (need to log in wtih TP-Link ID and bind your device to it)
Cloud management: TP-Link Aginet Unified Cloud (TAUC)
DHCP Server, DHCP Client List, Address Reservation
Redirecionamento de Portas Virtual Server, Port Triggering, UPnP, DMZ
DNS Dinâmico DynDns, NO-IP
VPN Pass-Through IPSec, PPTP, L2TP
Controle de Acesso Parental Controls, White List, Black List
Firewall DoS, SPI Firewall, IP and MAC Address Binding
Protocolos IPv4, IPv6
VPN Server PPTP, OpenVPN, IPSec
OUTROS
Conteúdo do Pacote AX1800 Dual Band WiFi 6 Router EX220
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
Requirements Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Subscription with an internet service provider (for internet access)
Ambiente Operating Temperature: 0?–40? (32?–104?)
Storage Temperature: -40?–60? (-40?–140?)
Operating Humidity: 10%–90% non-condensing
Storage Humidity: 5%–90% non-condensing
