On Shelf Date End of May, 2023
GPU AD104-150
Process nm 4
CUDA Cores 4352
Idle Board Power W N/A
Max Board Power W 165W
Power Connectors 8-pin
Idle GPU Temperature ? N/A
Max GPU Temperature ? N/A
Size 8GB
Type GDDR6
Memory Width 128-bit
Memory Bandwidth GB/s 288
Interface PCI-E 4.0
Dimensions(with Bracket) mm 251*133*41
Dimensions(without Bracket) mm 237*118*41
Boost Clock MHz 2550
Over Clock ?or× O
Memory Clock (effective) Gbps 18
Over Clock ?or× ×
1st output DisplayPort 1.4a
2nd output DisplayPort 1.4a
3rd output DisplayPort 1.4a
4th output HDMI 2.1a
5th output
Edge N/A
Software SLI / Crossfire ×
FAN 2*92mm
Slot 2
FAN Control ?or× O
Idle Noise Level (decibel) dB N/A
MAX Noise Level (decibel) dB N/A
Heatpipes / VC 4*6mm
RGB N/A
Other special features Top white LED with on/off switch
DirectX DirectX 12
Windows support Windows 10/11 64-bit
Minimum Power Supply 550W
Product Code 46ISL8MDABOC
EAN 4895147157115
Fan part number 527210-0125
PCB (Colour) D46Q (Black)
Box dimension mm 325*193*73
Carton dimension mm 705*440*330
Carton qty 16
Pilot Run Date N/A
Ship date N/A
